ALC1000S STANDARD THREE-PHASE ELECTRIC POWER SOURCE

Series:

Communication inverter variable frequency power supply

Single-phase AC variable frequency power supply adopts SPWM high-frequency pulse width modulation, advanced direct digital frequency synthesizer (DDS) waveform generation technology, providing a clean sine wave output; Output frequency: 40Hz-500Hz (10Hz-1000Hz customized), Output voltage: Low range 0-150V/High range 0-300V (0-2000VAC customizable). It can simulate standard or abnormal voltage and frequency states, and is applied to the production and research of test systems, electronic appliances, motors, lighting and other fields.

Product Inquiry

Details

Product Features

◆ Adopts advanced Direct Digital Synthesizer (DDS) waveform generation technology, with high frequency stability and good continuity;

◆ High measurement accuracy, suitable for testing various waveforms with DC components, such as sinusoidal half-waves and similar waveforms;

◆ Provides an embedded intelligent PC monitoring system;

◆ Fully adjustable output voltage: low range 0-150V, high range 0-300V, step 0.1V;

◆ Output frequency 45-120Hz (40-500 Hz optional), step 0.1Hz;

◆ Output current limiting function;

◆ Has 3 sets of memory, which can store commonly used parameters (voltage V, frequency F, current I) for easy recall during use;

◆ Has RS232C communication interface [IEEE488.2(GPIB) optional], instruction execution time less than 10ms; (Communication interface optional);

◆ Protection modes: overvoltage, overcurrent, overload, short circuit, current limiting, etc.;

◆ Provides RMS voltage, RMS current, active power, frequency, power factor, etc. readings;

◆ For 100% load and unload, the stable response time is within 20ms, with strong overload capacity, and the instantaneous current can withstand 3 times the rated current;

◆ Input and output isolation.

Product Applications

◆ Export of electrical appliances / electronics / motor manufacturing plants / switching power supplies / transformer testing

◆ Compressor / motor related product testing / monitor testing

◆ Air conditioning equipment testing / various electrical product testing

◆ Fluorescent lamp rectifier testing / manufacturing plants (quality assurance / control / life testing), etc.

◆ 400Hz output dedicated power supply: military systems, aviation systems, marine systems, switching power supplies for supercomputers, etc.

◆ Export of electrical appliances / electronics / motor manufacturing plants

Product Specifications

ALC1000S Standard Three-Phase AC Power Supply

Model

1006S

1009S

1012S

1015S

1020S

1030S

1060S

1100S

1150S

1300S

1450S

Power

12K

15K

20K

30K

60K

100K

150K

300K

450K

Working Method

SPWM (Sine Pulse Width Modulation)

INPUT

Phase

1φ2W

3φ4W

Voltage

220V±10%

380V±10%

Frequency

47Hz ~ 63Hz

OUTPUT

Phase

1φ2W

Voltage

Low range 0-150VAC / High range 0-300VAC

Frequency

45HZ-63HZ continuously adjustable, fixed 50HZ-60HZ, (40-500 optional)

Maximum Current

Max Current

L＝120V

16.8A

25A

33A

42A

56A

84A

168A

278A

420A

840A

1250A

H＝240V

8.4A

12.5A

17A

21A

28A

42A

84A

139A

210A

420A

652A

Display (A phase)

Voltage, Current, Frequency, Power, Power Factor PF

Linear Regulation

0.1%

Load Regulation

Harmonic T. H. D

2% (pure resistive load)

Frequency Regulation

0.01%

Voltage Resolution

0.1V

Frequency Resolution

0.1 Hz

Current Resolution

0.001A/0.01/0.1/1（A）

Measurement Accuracy

Accuracy

Voltage

0.5%FS+5dgt

Current

0.5%FS+5dgt

Wattage

0.5%FS+5dgt

Frequency

0.01%FS+5dgt

Setting Accuracy

Setting

Accuracy

Voltage

1%FS

Frequency

0.1%FS

Protection

Overcurrent, Overtemperature, Overload, Short Circuit

Operating Environment

Temperature: 0-45℃ Relative humidity 0-90％RH (non-condensing) Altitude 1500m

Insulation reactance

55Vdc 20MΩ and above

Withstand voltage insulation

1800vac/5mA/1 minute

Cooling Method

Forced Air Cooling

Additional Function

External Control 0~5V/10V/2.5V

Customized Features

Customizable Voltage, Current, and Dimensions

Size

Inquiry factory

Weight (Kg)

15kg~900kg

◆ Please contact the company for special specifications. The company accepts custom orders.
