DLC6000 SERIES PROGRAMMABLE DC POWER SUPPLY

Series:

The DLC6000 series switch-mode programmable DC power supply uses PWM technology, high-frequency switching, modular design, and advanced DSP digital control technology. It features constant voltage, constant current, and constant power output modes, with automatic cross-switching. It maintains a balance between control and protection, ensuring high-precision, low-ripple DC power output with fast voltage and current dynamic response, and an efficiency of up to 93%.

Product Inquiry

Details

The DLC6000 series switch-mode programmable DC power supply utilizes PWM technology, featuring a modular design and advanced DSP digital control technology. It offers constant voltage, constant current, and constant power output modes with automatic cross-switching, maintaining a balance between control and protection to ensure high-precision, low-ripple, and fast dynamic response of voltage and current output, achieving an efficiency of up to 93%. Compared to traditional thyristor power supplies, high-frequency switch-mode DC power supplies are smaller, lighter, have lower ripple, higher power factor, and better stability, especially noticeable in high-voltage output stability. The product is primarily targeted at electronic power production, battery industry, PCB manufacturing, communications, PLC power supply, electromechanical aging testing, DC motor testing, automated test system integration, medical devices, industrial applications, battery charging and simulation, hybrid electric vehicle and photovoltaic inverter testing research units, and laboratories requiring high-precision DC power supplies. It is used as a replacement for imported high-power DC power supply products.

Product Features

The DLC6000 series programmable DC power supply is a high-power, high-precision DC power supply with single-phase or three-phase AC input and DC output, with a maximum power of up to 400KW.

This series of power supplies boasts superior accuracy, precision, and stability. It provides high-power, ultra-low ripple DC power on production lines, enhancing product performance. It features comprehensive protection circuitry and, compared to switching power supplies, offers advantages such as high precision, low ripple, no high-frequency radiation interference, and wide applicability.

This series of products is an ideal DC regulated power supply, widely applicable in factories, schools, research institutes, laboratories, and various sectors of the national economy.

Specification Range: Output voltage 0～700V, output current 0～500A, output power 0～400KW (selectable)

◆ Constant Voltage and Constant Current: Voltage and current values are continuously adjustable from zero to the rated value, with automatic switching between constant voltage and constant current.

◆ Overvoltage Protection: Voltage protection value is continuously adjustable from 0～120% of the rated value. The output will trip if the output voltage exceeds the protection value.

◆ Short Circuit Protection: Allows for long-term short circuits in any operating state or short-circuit power-on.

◆ Programmable: Can be connected to a computer to form a computer-controlled intelligent voltage and current regulated power supply (standard configuration)

Product Applications

◆ DC motor testing, starting, and aging testing

◆ Electric vehicle motor testing and aging

◆ Electrolytic capacitor aging, tantalum capacitor energization

◆ Aging and routine testing of electronic components such as resistors, relays, motors, and transistors

◆ Electronic instrument system aging testing

◆ Other applications requiring high-power DC power supplies

Product Interface

Product Specifications

DLC6000 Series Programmable DC Regulated Power Supply
Model		DLC6000 Series Programmable DC Regulated Power Supply
Manufacturing Method		SPWM
Constant Voltage and Constant Current		Switchable Constant Voltage and Constant Current
Constant Voltage		Current Variation during Constant Voltage
Constant Current		Voltage Variation during Constant Current
Input	Number of Phases	1φ2W≤5K≥3φ4W≥5K
	Voltage	220V±10%/380V±10%
	Frequency	47HZ-63Hz
Output	Voltage	0-Max Customizable Voltage
	Current	0-Max Customizable Current
	Control Method	Button Control
Display: LED		Voltage, Current
Power Supply Regulation		0.1%
Load Regulation		1%
Efficiency		≥92%
Ripple		0.8%-2%
Voltage Drop Compensation		With automatic lead voltage drop compensation S1S2 (optional)
Voltage Resolution		0.01V
Current Resolution		0.001/0.01/0.1/1 (A)
Setting Accuracy	Voltage	0-100% Voltage Settable
	Current	0-100% Current Settable
Measurement Accuracy	Voltage	0.5%FS
	Frequency	0.5%FS
Protection		Overcurrent, Overtemperature, Overload, Short Circuit
Electromagnetic Compatibility		Input EMC filter
Input Method		Terminal Block
Output Method		Terminal Block (Busbar)
Operating Environment		Temperature: 0-45℃, Relative Humidity: 0-90%RH (non-condensing), Altitude: 1500m
Insulation Resistance		55Vdc 20MΩ and above
Withstand Voltage Insulation		1800Vac/5mA/1 minute
Cooling Method		Forced Air Cooling
Communication Interface		RS232C/485 Communication protocol provided
Analog Interface		Analog signals of 0-10V/5V/4-20mA for control and feedback are available
Customizable Functions		Voltage, current, and shape are customizable
Volume		Inquiry factory
Weight (Kg)		15kg~900kg

Product Selection Table:

Output Voltage	Output Current	Output Voltage	Output Current	Output Voltage	Output Current	Output Voltage	Output Current
0-12	0-500	0-15	0-500	0-20	0-500	0-24	0-500
	0-1000		0-1000		0-1000		0-1000
	0-1500		0-1500		0-1500		0-1500
	0-2000		0-2000		0-2000		0-2000
	0-3000		0-3000		0-3000		0-3000
	0-5000		0-5000		0-5000		0-5000
	0-10000		0-10000		0-10000		0-10000
0-30	0-500	0-36	0-500	0-48	0-500	0-60	0-500
	0-1000		0-1000		0-1000		0-1000
	0-2000		0-2000		0-2000		0-2000
	0-3000		0-3000		0-3000		0-3000
	0-5000		0-5000		0-5000		0-5000
	0-10000		0-10000		0-10000		0-10000
0-80	0-300	0-100	0-300	0-150	0-300	0-200	0-300
	0-500		0-500		0-500		0-500
	0-1000		0-1000		0-1000		0-1000
	0-2000		0-2000		0-2000		0-2000
	0-3000		0-3000		0-3000		0-3000
	0-5000		0-5000		0-5000		0-5000
0-300	0-100	0-500	0-100	0-800	0-50	0-1000	0-50
	0-200		0-200		0-100		0-100
	0-500		0-500		0-200		0-200
	0-1000		0-1000		0-500		0-500
	0-2000		0-2000		0-1000		0-1000

See table below:

Specifications and Model	Output			Specifications and Model	Output
Specifications and Model	Voltage	Current	Power	Specifications and Model	Voltage	Current	Power
DLC6000（600W）				DLC6000（1.2KW）
DLC6000	10V	60A	600W	DLC6001	10V	120A	1200W
	30V	20A			30V	40A
	60V	10A			60V	20A
	100V	6A			100V	1.2A
	150V	4A			150V	8A
	300V	2A			300V	4A
	600V	1A			600V	2A
	1000V	A			1000V	1.2A
	600V	1A			1500V	0.8A
DLC6002（3KW）				DLC6006（6KW）
DLC60003	10V	300A	3KW	DLC60006	10V	600A	6KW
	30V	100A			30V	200A
	50V	60A			50V	120A
	100V	30A			100V	60A
	150V	20A			150V	40A
	300V	10A			300V	20A
	600V	5A			600V	10A
	1000V	3A			1000V	6A
	1500V	2A			1500V	4A
DLC6010（10KW）				DLC6015（15KW）
DLC6010	10V	1000A	10KW	DLC6015	10V	1500A	15KW
	30V	334A			30V	500A
	50V	200A			50V	300A
	100V	100A			100V	150A
	150V	67A			150V	100A
	200V	50A			200V	75A
	300V	34A			300V	50A
	500V	200A			500V	30A
	800V	12.5A			800V	19A
	1000V	10A			1000V	15A
	1500V	7A			1500V	10A
DLC6020（20KW）				DLC6030（30KW）
DLC6020	10V	2000A	20KW	DLC6030	10V	3000A	30KW
	30V	667A			30V	1000A
	50V	400A			50V	600A
	100V	200A			100V	300A
	150V	134A			150V	200A
	200V	100A			200V	150A
	300V	67A			300V	100A
	500V	40A			500V	60A
	800V	25A			800V	38A
	1000V	20A			1000V	30A
	1500V	13A			1500V	20A
DLC6060（60KW）				DLC6090（90KW）
DLC6060	10V	6000A	60KW	DLC6090	10V	9000A	90KW
	30V	2000A			30V	3000A
	50V	1200A			50V	1800A
	100V	600A			100V	900A
	150V	400A			150V	600A
	200V	300A			200V	450A
	300V	200A			300V	300A
	500V	120A			500V	180A
	800V	75A			800V	113A
	1000V	60A			1000V	90A
	1500V	40A			1500V	60A
DLC6120（120KW）				DLC6150（150KW）
DLC6120	30V	4000A	120KW	DLC6150	30V	5000A	150KW
	50V	2400A			50V	3000A
	100V	1200A			100V	1500A
	150V	800A			150V	1000A
	200V	600A			200V	750A
	300V	400A			300V	500A
	500V	240A			500V	300A
	800V	150A			800V	188A
	1000V	120A			1000V	150A
	1500V	80A			1500V	100A
DLC6180（180KW）				DLC6240（240KW）
DLC6180	30V	6000A	180KW	DLC6240	30V	8000A	240KW
	50V	3600A			50V	4800A
	100V	1800A			100V	2400A
	150V	1200A			150V	1600A
	200V	900A			200V	1200A
	300V	600A			300V	800A
	500V	360A			500V	480A
	800V	225A			800V	300A
	1000V	180A			1000V	240A
	1500V	120A			1500V	160A
DLC6360（360KW）				DLC6480（480KW）
DLC6360	50V	7200A	360KW	DLC6480	100V	4800A	480KW
	100V	3600A			150V	3200A
	150V	2400A			200V	2400A
	200V	1800A			300V	1600A
	300V	1200A			500V	960A
	500V	720A			800V	600A
	800V	450A			1000V	480A
	1000V	360A			1500V	320A
	1500V	240A
Note: Voltage 1500V-3000V is customizable, power 480KW-1500KW is customizable

Note: Please call for more specifications, please call for special specifications, or call our sales department;
The product shall be subject to the actual object, the picture is for reference only. Specifications are subject to change without notice.
